RFID Reader
release date:2020-07-06 13:15:24Click volume:
Technical Parameter
Dimension | 260mm*21mm*43mm |
Weight | 580g |
Frequency | 920~928 Mhz/865-868Mhz |
Protocol | EPC C1 Gen2/ISO 18000-6C |
Chip | impinj R2000 |
CUP | Freescale MPC8303 |
Memory | 128 M |
flash memory | 8M+256M(optional) |
Output power | 10~32.5dBm(adjustable) |
Communication interface | USB,RJ45,Wifi,RS232,GPIO |
Antenna portal | 4TNC |
Power supply | DC 24V/2A |
Power consumption | 30W (typical value) |
Working temperature | -20℃~+50℃ |
